Tuning a fuel table cell by cell takes time: hold the engine at a speed and load, read the mixture, correct the cell, move to the next. The adaptation table lets the RM-Primis ECU do that work for you while you drive. It is the ECU's fuel autotune: it compares the mixture the wideband sensor measures with your lambda target, works out how much each area of the fuel table is off, and keeps that correction, cell by cell, in this table. You then apply the corrections to the fuel table with one button.
The learning runs inside the ECU, so no laptop needs to be connected while you drive. The next time RM-Tuner connects, it reads what the ECU has learned.
Video: Adaptation table / autotune how-to
The adaptation table has the same RPM and load axes as the fuel table, so each of its cells belongs to the fuel table cell in the same place.
While the engine runs, the ECU watches the measured mixture against the target. When the engine has stayed at a steady load for long enough, it takes the error (the mixture error plus what the closed loop is already correcting) and moves the adaptation cell for that place a step towards the correction it needs. Priority sets how big each step is. Visit the same area again and again, and the cell settles on the correction that area needs.
An example. You cruise at 2500 rpm and 45 kPa, where the target is 14.7 AFR. The fuel table cell is 4 % lean, so the closed loop is adding 4 %. Over a few visits, the adaptation cell at 2500 rpm and 45 kPa climbs to +4.0. Press Apply to VE: that fuel table cell goes up by 4 %, the engine runs on target without help, and the closed loop goes back to correcting almost nothing.
It only learns when the reading can be trusted. It waits:
Open Tune → Fuel → Adaptation. The settings are in Adaptation settings under the table. The table is filled in by the ECU and read by RM-Tuner; you do not edit it by hand.
The picture shows a table after a few drives: the ECU has learned corrections where the car idled and cruised (low load, up to about 3000 rpm), and left the rest at 0. Positive cells need more fuel, negative cells less. The pattern is typical: the biggest corrections sit at idle and very light load, where the fuel table is hardest to get right by hand.
| Setting | What it does |
|---|---|
| Enabled / Disabled | Switches the adaptation on and off. It is the same switch as Adaptation on Fuelling settings |
| Upper limit / Lower limit | The most a cell may be corrected up or down, up to ±40.95 % |
| Priority | How much of the measured error is learned at each step. High learns faster but can swing back and forth; low filters out spikes on a table that is already close |
| Const. load time | How long the load must stay steady before a cell is learned, so it learns at steady running and not while the throttle moves |
| Cell tolerance | How steady is steady: a manifold pressure change of this much or more starts Const. load time again. 0 means 2.50 kPa. In Alpha-N, or with no MAP sensor, a 2 % throttle change is used instead |
| Autotune | Active once the adaptation is on and the engine is warm enough to learn; Warm-UP otherwise |
| Refresh | Reads the learned values from the ECU again |
| Apply to VE | Applies the learned corrections to the fuel table: a cell reading +5 raises the fuel table cell in the same place by 5 % |
| Clear | Empties the adaptation table, to start learning again |
If your engine's manifold pressure moves more than Cell tolerance even at a steady load (often the case at wide open throttle), widen it so the adaptation can learn there.
If a cell keeps swinging between positive and negative values, it is learning while the load changes: raise Const. load time. Learn full load on a dyno or a closed road, never on public roads.
Instead of learning in the ECU, RM-Tuner can work out corrections from a datalog: on the fuel table, open Fuel analyser → Build from a log... in the Table information panel. It reads the mixture error the log recorded and weights it onto the fuel table's cells. It is useful after a dyno session, or for the areas you only pass through briefly.
Yes. RM-Tuner's fuel autotune is the adaptation table: the ECU learns fuel corrections from the wideband sensor while you drive, and you apply them to the fuel table.
No. The ECU learns on its own and keeps the values; RM-Tuner reads them the next time it connects.
Check that Autotune reads Active, that the wideband sensor is ready, that no sensor fault is stored, and that you hold the load steady long enough for Const. load time.
Contact customer support at [email protected].
